The SMARTPILOT WIRE is a Class C LoRaWAN® actuator that monitors and controls up to 6 operating modes for any electric heater as well as any active load (ON/OFF) driven by a relay.
| Model : | SMARTPILOT WIRE (Ref: 50-70-027) |
| Applications : | Electric heater remote management, demand side management, switched relay control, smart lighting |
| Function : | Class C LoRaWAN® actuator (smart pilot wire modes + switched relay) |
| Protocol / Radio : | LoRaWAN® Class C (document also notes Class A firmware lines) — EU 863–870 MHz; TX +14 dBm; Sensitivity -140 dBm |
| Power supply : | 230 V AC / 50 Hz |
| Enclosure size / IP : | 76 × 41 × 17 mm / IP30 |
| Operating temperature : | -20 °C to +50 °C |
| User interface : | 3 LEDs, magnetic switch (Reset, ON/OFF) |
