VAQA'O+ Lite Temperature Humidity CO2 Luminosity & Presence sensor
,

VAQA’O+ Lite Temperature Humidity CO2 Luminosity & Presence sensor

£210.03

Get Trade Price
Add to Quote
Compare

The VAQA’O+ sensor measures temperature, relative humidity, atmospheric pressure, Volatile Organic Compounds (VOC) and Carbon Dioxide (CO2) concentrations… VAQA’O+ is used to monitor Indoor Air Quality (IAQ) according to presence thanks to the detection of luminosity (lighting) and the movement of people (PIR) in the room. The data is transmitted via a public or private LoRaWAN® radiofrequency network.

SKU: 50-70-251 Categories: , Brand:
Model : VAQA’O+ (Ref: 50-70-074)
Applications : Supervision HVAC, Indoor Air Quality monitoring (schools, hospitals, etc.), Energy optimisation
Measurements : Temperature, Hygrometry, Atmospheric pressure, CO₂, VOC, Brightness, Motion (PIR)
Temperature range : 0 °C to +55 °C
Temperature accuracy : ±0.2 °C
Hygrometry range / accuracy : 0% to 100% rH / ±2%
Atmospheric pressure range / accuracy : 300 to 1100 hPa / ±0.6 hPa
CO₂ range : 0 to 5000 ppm
VOC index : 0 to 500 / ±5
Brightness : 0.01 Lux to 83,000 Lux / 5%
Motion : Up to 12 m, 102° × 92° detection
Battery : 3 × 3.6V / 2500 mAh
Autonomy : > 3 years (default: 1 meas. every 10 min, 1 tx / hour, with compression)
Radio / Protocol : LoRaWAN® Class A, EU 863–870 MHz; TX +14 dBm; Sensitivity -140 dBm
Size / IP : (not specified as single line in sheet) — sensor enclosure typical for wall mounting; IP rating per
datasheet
Operating temp : 0 °C to +55 °C

Download Datasheet
