Elsys ELT Ultrasonic Outdoor LoRaWAN® Wireless Sensor
, , ,

Elsys ELT Ultrasonic Outdoor LoRaWAN® Wireless Sensor

It can be placed in various environments to measure distance.

£391.48 (£469.78 incl. VAT)

Get Trade Price
Add to Quote
Compare

The ELT Ultrasonic is designed for measuring the distance. It can be placed in various environments and can work as a bin level sensor, tank level sensor, or water level under bridges, for example.

ELT Ultrasonic distance sensor can be placed in various environments to measure distance as well as temperature, humidity, and atmospheric pressure. It is enclosed in an IP67 box and is designed to be mounted outside. ELT Ultrasonic is the ideal sensor for measuring in advanced places or extreme weather conditions, and has the capacity of measuring with remarkably long range.

Not only can you measure distance with the ELT Ultrasonic, but it also has four internal sensors: temperature sensor, humidity sensor, accelerometer, and an atmospheric pressure sensor. It is enclosed in an IP67 box which makes it ideal for mounting outside or in extreme conditions.

Applications

  • Bin and tank level measurements
  • Water level measurements (under bridges or wells e.g.)
  • Smart cities
  • Agriculture
  • Industries
  • Extreme weather conditions
  • Exposed areas (containers e.g.)

Product features

  • LoRaWAN Certified CM
  • Compatible with LoRaWAN® 1.0.3
  • Measures ambient temperature
  • Measures ambient humidity
  • Detects acceleration
  • Measures ambient atmospheric pressure
  • IP67 Classified
  • Battery-powered
  • NFC for configuration
  • Configuration over the air

LoRaWAN_Elsys_ELT_Ultrasonic_LoRaWAN®_Wireless_Sensor_Data_Sheet (182KB)



Categories: , , , Brand:
Mechanical Specifications
Weight 195 g excluding batteries / 215 g including batteries
Dimensions 94 x 59 x 35 mm excluding horn / 94 x 59 x 85,7 including horn
Enclosure IP67
Direct connection to: Maxbotix ultrasonic distance sensor
Operating Conditions
Temperature –40 to 60 °C (85 °C with external power supply)
Humidity 0 to 100% RH
Device Power Supply
Battery Type 1 x 3.6V AA Lithium Batteries
Expected Battery Life <10 years (Depending on configurations and environment)
Device Logging Functions
Sampling Interval Configurable via NFC and downlink configuration
Data Upload Interval Configurable via NFC and downlink configuration
Radio / Wireless
Wireless Technology LoRaWAN® 1.0.3
Wireless Security LoRaWAN® End-to-End encryption (AES-CTR), Data Integrity Protection (AES-CMAC)
LoRaWAN Device Type Class A/C (configurable) End-device
Supported LoRaWAN® features OTAA, ABP, ADR, Adaptive Channel Setup
Supported LoRaWAN® regions US902 – 928, EU863 – 870, AS923, AU915 – 928, KR920 – 923, RU864, IN865
Link Budget 137 dB (SF7) to 151 dB (SF12)
RF Transmit Power 14 dB / 20 dB (Region specific)
Ultrasonic Distance Sensor
Distance Range 30 cm – 5 meter. Targets closer than 30 cm will typically range as 30 cm
Range Output Serial, 1 mm resolution
Dimensions Length 50.7 mm. Outer diameter 43.8 mm.
Model MaxBotix MB7389 HRXL-MaxSonar-WRMT
Data Types
Type value Type Data size Comment
0x01 Temperature 2 -3276.5 °C – 3276.5 °C (Value of: 100 → 10.0 °C)
0x02 Humidity 1 0 – 100 %
0x07 VDD (Battery voltage) 2 0 – 65535 mV
0x0E External distance 2 0 – 65535 mm
0x0F Motion (Acceleration) 1 0 – 255 (Interrupts from accelerometer)
0x14 Pressure 4 Pressure data (hPa)
0x3D Debug information 4 Data depends on debug information
0x3E Sensor settings n Sensor setting sent to server at startup (first package). Sent on Port+1.
